Allowing ETL access to my data on Xero ETL can access your Xero data. This article details creating the Xero connection and the process of building a data pipeline to read Xero data in ETL. There are also pre-built templates to read data from Xero. Please see Create a package from a template for instructions on using a template.

To create a Xero connection in ETL:

    1. Click the Connections icon (lightning bolt) on the top left menu.
    2. To create a connection, click New connection.thumbnail image
    3. Choose Xero.
    4. Click Authenticate. (If required, sign in to Xero)
    5. Click Connect to authorize ETL access to your Xero account.
    6. In the new new Xero connection window, name the connection and click Create Xero connection.

To modify Xero connections in ETL:

    1. Click the Connections icon (lightning bolt) on the top left menu.
    2. Click a connection to re-connect if your password has changed or the token has expired.
    3. To delete a Xero connection, click on the three vertical dots on the far right of the connection listing and select the Delete connection option.

To build a data pipeline to read Xero account data in ETL:thumbnail image

REST API Component: accounts

  • Authentication - Click Connection and then select your Xero connection. If you haven't created your Xero connection yet, click + New and follow the instructions found above. thumbnail image
  • URL - Enter the URL for the Accounts endpoint of the Xero API: Make sure the method is set to GET. Click Add beneath Headers twice to add the following two headers: Accept: application/json, If-Modified-Since: $last_updated_at. Replace the variable $last_updated_at with a timestamp for the minimum age of the updated data. thumbnail image
  • Response - Make sure the JSON response type is selected.  Edit the Base record JSON Path Expression field like this: $.Accounts[*].thumbnail image
  • Input fields - Click Select all to move all the Available fields over to the Selected fields or pick and choose which fields you would like by clicking on the + icon next to the field name in the Available Fields column. Then click Save. thumbnail image

Select Component: parse_account_fields

  • Click Autofill to bring in all the fields from the source component. Convert the UpdatedDateUTC field into a datetime data type using these functions: ToDate((long)REPLACE(REPLACE(UpdatedDateUTC,'\\/Date\\(',''),'\\+.*','')). Click Save. thumbnail image

Destination Component: xero_accounts_destination

  • The template shows a Redshift destination component; however, if you'd prefer to use a different destination, delete the Redshift component and select a destination component of your choice.thumbnail image
  • Choose target connection - Select your target connection. If you haven't created your connection yet, click + New. thumbnail image
  • Destination properties - Fill in the values for target schema and table, select an operation type, pre or post-action SQL, and advanced options.
  • Schema mapping - Click Auto-fill to bring in all of the fields. If you've selected a Merge operation type, click the Key box next to the merge key field(s). Click Save.thumbnail image
